Customized for Application device !

Pls email us to ASK for the TEST report and free samples.

【 Download 】

DataSheet : http://docs.antennahome.com/ant/AH5G.228.pdf
Catalogue : http://docs.antennahome.com/ant/catalogue.pdf


【 Features 】

300MHz~ 6GHz wireless system

-40~85^。C work temp .

【Products 】
Antenna

- All frequency range antennas from 300MHz to 6GHz ;
- Covered ISM band ,315M/433M/470/868M/915M/2.4G;WIFI/BT/ZIGBEE,Z-wave ; 2G-GSM/GPRS/3G--WCDMA/4G-LTE/5G;  NB-IoT/Cat.1; LoRa; UWB ;RFID-915M/2.4G;GNSS/GPS/BD;
- Internal antenna ,chip antenna,spring antenna ,metal antenna ; pcb+cable ,fpc+cabel ;
- External antenna ,Rubber antenna ,Metal antenna,Magnetic antenna ,On-box antenna ,Directly antenna ;fiberglass antenna ;

RF Cable Assy

- All kinds cable assembly with connector and cable
Connector : SMA/SMB/MCX/MMCX,BNC/TNC/N-TYPE,Fakra,U.FL/IPEX/IPX/,
Cable : RG113/RG-174/RG178/RG316;

RF connector

- SMA/SMB/MCX/MMCX,BNC/TNC/N-TYPE/F-TYPE,Fakra,U.FL/IPEX/IPX/,

Our Advantage

【 R&D Dept. 】

- More then 15 years RF engineers .
- Excellence sales manager who followed end customers .
- Professional RF performance test lab with Network analyzer, Spectrum analyzer ;3D OTA chamber ;

【 Manufacture 】

- 800+ square meter workroom ;
- All produce program under ISO9001 system ;
- 100% tested before delivery ;
